The MULTI 60-PLUS AC / DC is a small universal charger with easy-to-use power supply for home charging of all types of batteries. The MULTI 60-PLUS allows you to charge and discharge common types of cells (NiCd, NiMH, Li-Poly, Li-Ion, Li-Fe, LiHV, Pb) and is equipped with a built-in four-channel balancer for a very safe and comfortable charging of lithium batteries.

• Power supply 100-240 V / 50-60 Hz
• For charging and discharging 6-8 NiCd / NiMH cells, 2-4 Li-ion / Li-poly / Li-Fe / LiHV cells or 6-12 Lead lead accumulators
• Adjustable charging current (0.1 A – 6.0 A)
• Adjustable discharge current (0.1 A – 2.0 A)
• Max. power for charging 60 W, discharge 10 W
• Automatic charging and discharging mode for NiCd, NiMH with adjustable current limit
• Charging termination with the delta-peak for NiCd and NiMH accumulators
• Lithium and Pb accumulators are charged using the “Constant Current / Constant Voltage”
• Adjustable sensitivity of delta-peak detection for NiCd and NiMH accumulators
• Adjustable terminal voltage for charging and discharging for lithium batteries
• Repeated cyclic charging / discharging or discharging / charging operations for NiCd and NiMH accumulators up to 5 cycles
• Four charging modes for lithium batteries – normal charging, fast charging, charging with balance and storage charging / discharging. The last two modes require a balancing set service connector to connect, and other modes can be charged with or without balancing.
• End charging when the set time, charge charge or cut-off temperature is exceeded.
• Memory for 5 charging / discharging programs for each type of battery.
• Measure the total voltage of the set and individual cells (for lithium batteries).
• Measurement of total internal resistance of set and individual cells (for lithium accumulators)” / li>
• Socket for temperature sensor.
• XT60 Charger Output Socket.
• Two-line backlit LCD display with easy and clear menu and parameter display during charging / discharging
• A number of warning text messages are contributing to safe operation – incorrect input voltage, poor wiring, unsuitable battery or condition, incorrect polarity at output
• Reverse polarity protection and short circuit protection.
• Compact plastic cabinet, small size
• Built-in ventilator for forced cooling
• Built-in power supply.

The charger is equipped with a JST-XH balancer socket to connect the 2S, 3S and 4S sets directly. For the service connectors of other systems, you will need a suitable adapter.

You can purchase a temperature sensor to measure the temperature of the charged / discharged batteries.

Note: When charging lead-acid accumulators, the charger uses a terminal voltage of 2.40 V / cell – this is why it is suitable for charging classic lead-acid batteries and rechargeable gel batteries. To charge gas-tight gel batteries that can not be charged at more than 2.30 V / cell, do not fit.

The charger kit includes: MULTI 60-PLUS AC / DC charger , power cord, charging cable with TAMIYA and T-DYN connector , instructions.
